Physics Team 3B SEA 1008532. Electricity and magnetism, 41 experiments

Set of devices for carrying out 41 experiments by students of electricity and magnetism. In a stable plastic box with formed foam insert for the devices and with transparent lid. Includes CD with experimentation instructions. The experiments are mounted and carried out in a small space, but clearly, on the base plate SEA 1000789 (U8408035)

Scope of delivery:
1 set of experiment cables
1 bar magnet, approx. 65x16x5 mm³
1 Horseshoe magnet, ALNICO, flat
1 Resistance table
1 Transformer core 20x20 mm²
1 Tensioning screw
1 Coil 200/400/600 turns
1 Coil 400/400/800 turns
2 Current branches (plug-in element)
1 Potentiometer 100 Ω (plug-in element)
1 Switch (plug-in element)
1 Capacitor 4700 μF (plug-in element)
1 Capacitor 10 μF (plug-in element)
1 Resistor 33 Ω (plug-in element)
1 Resistor 47 Ω (plug-in element)
1 Resistor 1 kΩ (plug-in element)
1 NTC resistor 100 Ω (plug-in element)
2 E10 sockets (plug-in element)
2 E10 incandescent lamps, 7 V
1 Storage jar with O-ring thread set, 2 threaded bushings, 2 threaded pins, 2 office clips, 2 aluminum electrodes, constantan wire
50 g Iron powder
50 m Nickel chromium wire, 0.2mm
50 m Iron wire, 0.2 mm
1 Candle te


Includes 41 experiment guides for electricity and magnetism.

Required:
- AC/DC power supply for Electricity and Magnetism SEA AC/DC 1008532.

- Physical equipment 3B SEA 1000789. Motherboard assemblies 400x245x15 mm (Art. 21015)
